Steel Water Transmission Pipes — ERW, LSAW & HSAW
Mill-certified carbon steel pipes for municipal waterlines and transmission mains. API 5L Grade B to X70 · EN 10217 · OD 21.3 mm to 2,540 mm.
Water Transmission Pipe Types
Choose the right manufacturing route based on design pressure, diameter, joint configuration and project standard.
ERW Pipes for Water Distribution
Cost-effective welded pipes for small to medium diameters and municipal distribution networks under API 5L / EN 10224 scope.
LSAW Pipes for High-Pressure Mains
Longitudinal SAW pipes (UOE/JCOE routes) for trunk lines with higher pressure requirements and heavy wall thickness.
HSAW/SSAW Pipes for Large Diameter
Large-bore municipal infrastructure pipelines with efficient cost structure for higher diameters and long-distance lines.
API 5L Grades and Dimension Guide
Reference ranges used in municipal and industrial water transmission procurement.
API 5L Grade Comparison
| Grade | Min. Yield (MPa) | Min. Tensile (MPa) | Typical Use |
|---|---|---|---|
| Grade B | 241 | 414 | Low-pressure distribution |
| X42 | 290 | 414 | Municipal transmission |
| X52 | 359 | 455 | Main transmission grade |
| X60 | 414 | 517 | High-pressure trunk lines |
| X65 | 448 | 531 | Long-distance transmission |
| X70 | 483 | 565 | Special high-pressure projects |
Diameter / Wall Thickness Reference
| Pipe Type | OD Range | WT Range | Indicative Weight |
|---|---|---|---|
| ERW | 21.3–355.6 mm | 2.8–12.7 mm | 1.40–105.6 kg/m |
| LSAW | 406.4–1219.2 mm | 6.4–25.4 mm | 63.2–762.3 kg/m |
| HSAW | 406.4–2540 mm | 5.0–22.0 mm | 49.0–1,380 kg/m |
PSL1 vs PSL2
| Requirement | PSL1 | PSL2 |
|---|---|---|
| Chemistry limits | Standard | More restrictive |
| Toughness testing | Not mandatory | Mandatory |
| Traceability | Standard | Full heat traceability |
| Weld inspection | Hydrostatic + weld seam UT or EM flux leakage | Hydrostatic + full-body UT (seam + body) or radiographic inspection |
| Hydrostatic test | Required | Required |
Coatings & Linings
| Type | Standard | Temperature | Typical Use |
|---|---|---|---|
| 3LPE | ISO 21809-1 / DIN 30670 | -40°C to +80°C | Buried pipelines |
| FBE | ISO 21809-2 | -40°C to +95°C (continuous) | High-demand buried service |
| CML | AWWA C205 | Water service | Potable water mains (NSF/ANSI 61 options) |
| Liquid Epoxy | AWWA C210 | Water service | Raw/industrial and potable water lines (NSF/ANSI 61 options) |
| Cathodic Protection | ISO 15589-1 | Buried service | External corrosion control with coated pipelines |
Get a Competitive Water Pipe Quote
Steel Pipes from Turkey?
Send your full specification and get a detailed offer including MTC scope, lead time, coating options and delivery terms.
Why Source Water Transmission Pipes from Turkey?
Turkey combines certified mill capacity with short sea routes to Europe, MENA and nearby regions.
Competitive Landed Cost
Export-oriented mills and strong logistics help optimize landed procurement cost.
Fast Regional Freight
Typical CIF transit windows are attractive for MENA, Europe and North Africa buyers.
Certified Mill Network
API 5L, EN 10224 and EN 10217-1/-4 capable mills with project-grade QA documentation.
Independent QA Flow
Inspection and document review support before shipment release.
Quality Assurance and Documentation
All supplied pipes are sourced from certified mills with full traceability and inspection records.
MetalFromTurkey is a trading company. We source from certified mills and coordinate QA, inspection and document flow for your project.
MetalFromTurkey QA Team — Water Infrastructure SupplyTypical End-Use Sectors
Water transmission supply for public and industrial infrastructure programs.
Municipal Water Utilities
City and regional transmission mains and network upgrades.
EPC Infrastructure Contractors
Large-volume project procurement and staged deliveries.
Industrial Cooling Networks
Process and cooling water systems for heavy industry and energy facilities.
Irrigation Projects
Long-distance irrigation trunk lines and distribution systems.
How to Order
Simple RFQ workflow from technical scope to documented shipment.
Submit RFQ
Share type, grade, dimensions, quantity, joint type and delivery location.
Receive Offer
Get detailed commercial and technical quotation promptly.
Confirm Order
Finalize production scope and secure mill schedule.
Inspection
Coordinate QA checks, NDT scope and optional SGS/BV/LR witness.
Ship & Deliver
Receive shipping documents, MTC package and delivery updates.
Common Questions
What types of steel pipes are used for water transmission?
ERW is typically used for smaller diameters, LSAW for higher pressure trunk lines, and HSAW/SSAW for large municipal diameters up to 2,540 mm.
Which API 5L grades are common for water transmission?
Grade B, X42 and X52 are common. X52 PSL2 is frequently specified for municipal transmission mains, while X60/X65 are selected for higher pressure lines.
Do you provide mill test certificates?
Yes. EN 10204 3.1 MTC is standard and 3.2 third-party countersigned certification can be arranged on request.
What standards are typically specified for steel water transmission pipe?
Typical project packages reference API 5L for pipe grade, EN 10224 for aqueous-liquid service in Europe, and AWWA C200 as the base steel water pipe standard, with C205/C210 for linings and coatings.
What coatings and linings are available?
External options include 3LPE (ISO 21809-1) and FBE (ISO 21809-2, -40°C to +95°C continuous). Internal options include cement mortar lining (AWWA C205) and liquid epoxy (AWWA C210), with NSF/ANSI 61 formulations for potable-water projects when required.
Which joint types can be supplied?
Butt-welded ends are the most common for transmission mains. Flanged and mechanical coupling-compatible end preparations can also be supplied where project design requires maintenance access or equipment tie-ins.
Do buried water pipelines require cathodic protection?
Yes. For buried steel lines, external coatings are typically paired with cathodic protection per ISO 15589-1 or project CP specifications to control long-term external corrosion.
How quickly can you deliver from Turkey?
Transit and production timing depend on size and scope. For common regional destinations, practical shipping windows are often competitive after production release.
Request Your
Water Pipe Quote
Send your specification and receive a detailed proposal with price, MTC scope, lead time and delivery terms.
